Home > Products & Services > Precision Agriculture > AG992

High Precision

RTK mode: An accuracy of 2.5cm can be achieved.
Single-point mode: the accuracy is <30cm (single-point smoothing algorithm).

Stable & Strong Signal

Supports multi-constellation including BeiDou, GPS, GLONASS, Galileo, QZSS.More accurate positioning, Strong anti-interference ability, and Continuous and stable signal.

Terrain Compensation

The terrain compensation function can improve accuracy when driving straight lines across sloping or rough terrains with minimized skips and overlaps.

Guidencer Line Import&Sharing

The Auto-Steering software can also support guidance line import and sharing, users can import existing guidance line to the working field by USB and share guidance lines with other tractors in the same field.

Easy Installation & Debugging

AG992 system adopts a modular design, which is easy to install and use. Users can install and debug by themselves according to the guidance, and the transfer operation between different vehicles is also more convenient.

Multiple Working Modes

The system supports multiple operating modes: straight line, curve, A+ navigation line, 90°straight line, circular curve, etc., to meet various operation scenarios.

Features

Documents

Supports multiple constellations & frequencies:
-GPS L1, L2, L5
-GLONASS L1, L2
-BeiDou B1, B2, B3
-Galileo E1, E5a, E5b
-QZSS L1, L2, L5

Small high-torque motor

Highly integrated system

10.1'' touch screen control tablet

Auto-Steering error less than 2.5cm

Without modification of the hydraulic system

Fast installation in 30 minutes

Calibration in 15 minutes

Quick start in 5 minutes’ learning

AG992 has been tested for CE & FCC regulations.

Datasheet_AG992
Release Date: 2024-04-10 Version:1.2
Item List_AG992
Release Date: 2024-04-11 Version:1.3
